3D Scanning & Digitisation
Capture any object or plant asset as accurate digital data — and stop there if that's all you need.
- On-site or in-studio capture
- High-resolution point clouds & mesh
- Standard file formats you own
3D Scanning · Reverse Engineering · CAD · Perth, WA
From physical
From physical
to precise digital.
High-accuracy 3D scanning and CAD modelling for mining, industry and makers. Need an asset digitised into an accurate model you own? Stop there — or let us reverse-engineer and manufacture the part. Your scope, your call.
Perth, WA
Autodesk CAD
Industrial-grade tolerances
Files you own
Services
Pick exactly what you need. Many clients engage us for scanning and CAD alone — and take the model elsewhere. Others want the full path through to a finished part. Both are core to what we do.
Reverse Engineering & Scan-to-CAD
Turn scans of obsolete or undocumented parts into a clean, parametric CAD model you own.
- Scan-to-CAD conversion
- Wear & damage reconstruction
- As-built documentation
CAD Design & Modelling
Sketches and concepts modelled into production-ready 3D parts with Autodesk.
- 2D→3D Conversion
- Parametric Modelling
- Technical Documentation
Manufacturing & 3D Printing
When you want the finished part, we produce it — prototype to end-use, via vetted partners.
- PLA, ABS, Nylon
- Metal (Steel, Aluminium)
- Custom & replacement parts
Scan-only? Here's how it works
Just need it scanned into CAD?
No part to manufacture, no design work — just an accurate digital model of your object or asset, delivered in the files you need. It's one of our most-requested services for mining, industry and engineering teams.
Enquire about a scan-
1
Tell us the object
Share what needs capturing — a component, assembly or plant asset — and the accuracy and file format you need.
-
2
We scan it
On-site or in-studio, we capture high-resolution geometry and process it into a clean point cloud or mesh.
-
3
You receive the model
You get an accurate digital model you own, ready to work from. Take it elsewhere, or come back to us for design and manufacturing anytime.
The Process
From concept to reality in six steps — and you can stop at any point. Many engagements end at the verified CAD model.
-
1
Tell us what you need made
Initial Inquiry
Share the part, challenge or idea. If it exists, is broken, or is hard to source, we can work from it.
-
2
We define the best path forward
Analysis & Planning
We assess feasibility, materials, tolerances and the production pathway to ensure success.
-
3
The part is digitally defined
CAD Modelling & Capture
We model from sketches, photos or existing parts. High-accuracy 3D scanning ensures exact alignment.
-
4
Digital validation
Verification & Approval
You review the detailed 3D model and specs. We confirm everything matches before production.
-
5
Your part is brought to life
Manufacturing & Production
Once approved, the part is manufactured using the most appropriate 3D-printing or machining technology.
-
6
Checked, finished, and delivered
QC & Delivery
Every part is inspected, post-processed and securely packaged for delivery or local collection.
What's Possible
A snapshot of the kind of work we take on — not the limit of it. From a single scan to a finished part, if it can be captured, modelled or made, bring it to us.
Reverse Engineering
Classic Car Component
Recreated a disintegrated dashboard bracket for a 1968 classic. We scanned the fragments and reconstructed the geometry for a perfect fit.
ABS-Like Resin · 0.1 mm accuracy
3D Scanning
Precision 3D Scanning
Captured a worn engine housing with structured-light scanning, turning the physical part into an accurate digital mesh ready for modelling and reproduction.
Structured light · 0.05 mm resolution
Prototyping
Custom Drone Frame
Lightweight, aerodynamic frame optimised for stiffness-to-weight on a custom build.
Carbon-Fibre Nylon · 45 g
Restoration
Vintage Camera Mechanism
Reproduced a tiny internal mechanism from a broken original, restoring full functionality to a 1950s rangefinder camera.
Brass · 0.05 mm precision
Representative examples.
Priced on complexity, not guesswork
Every part is different. We anchor with starting points, then quote precisely once we understand the geometry.
Scan & Model
Digital twin only — a precise, editable CAD file you own.
From $150
AUD · final price quoted on scope
- 3D scan of original
- Parametric Autodesk model
- STEP + STL files delivered
Scan, Model & Print
The full pipeline — from original part to a finished physical replacement.
From $1,200
AUD · final price quoted on scope
- Everything in Scan & Model
- Material selection & advice
- Production via vetted partners
Complex / Assembly
Multi-part assemblies, metal processes and safety-relevant work.
Custom quote
Tailored to scope
- Assembly reverse engineering
- Metal & specialist materials
- Engineering consultation
Starting prices in AUD with a $150 minimum engagement. Final cost reflects part complexity, condition and material, and includes two rounds of revisions. Complex or assembly work is always individually quoted.
About 3D printing & fitness-for-purpose
ApexForm specialises in reverse engineering and CAD modelling. Physical printing is fulfilled by vetted third-party additive manufacturing partners. Material properties, tolerances and suitability for load-bearing or safety-critical applications depend on the chosen process and material, and remain the client's responsibility to validate.
We provide geometry and CAD-accuracy assurance; final part fitness-for-purpose should be confirmed by the client for the intended application.
Tell us about your part
Five quick steps. We'll review and reply within one business day.
Request received
Thanks — your request has been sent and we'll be in touch within one business day. A confirmation will arrive at the email you provided. Questions? Reach us at info@apexform3d.com.au.
Common questions
Turnaround varies by complexity. CAD design is generally 3–5 days. With manufacturing, expect 2–3 weeks for 3D printing and shipping. Expedited service is available for urgent requests.
Not at all. We can work from hand sketches, photos with measurements, or even the broken part itself. If you can send us the physical part, we can reverse-engineer it directly.
We typically provide STEP, STL and IGES — industry standards for manufacturing. Native Autodesk files are available on request.
Yes. Through our manufacturing partners we offer Stainless Steel (316L), Aluminium, Titanium and Tool Steel, plus high-performance polymers like Carbon-Fibre Nylon.
Standard CAD modelling tolerance is ±0.1 mm. For reverse engineering we use high-precision calipers and scanning tools so the part fits and functions exactly like the original.
Yes, we ship parts worldwide, and digital CAD files can be delivered instantly by email to clients anywhere.
